| Caméra |
|
| Capteur D'image |
CMOS à balayage progressif 1/2,7" |
|
Résolution
|
2560 × 1920 |
| Min. Éclairage |
Couleur : 0,001 Lux @(F1.0, AGC ON), 0 Lux avec Lumière Blanche |
| Temps D'obturation |
1/3 s à 1/100 000 s |
| Jour Nuit |
Imagerie couleur 24h/24 et 7j/7 |
| Réglage De L'angle |
Panoramique : 0° à 360°, Inclinaison : 0° à 90°, Rotation : 0° à 360° |
| Lentille |
|
| Type D'objectif |
Objectif focal fixe, 2,8 et 4 mm en option |
| Distance Focale Et Champ De Vision |
2,8 mm, champ de vision horizontal 95°, champ de vision vertical 70°,champ de vision diagonal 125° 4 mm, champ de vision horizontal 76°, champ de vision vertical 57°, champ de vision diagonal 98° |
| Monture De Lentilles |
M12 |
| Type D'iris |
Fixé |
| Ouverture |
F1.0 |
| Image |
|
| Commutateur Jour/Nuit |
Jour, Nuit, Auto, Calendrier
|
| Large Plage Dynamique (WDR) |
120 dB |
| Amélioration D'images |
BLC, HLC, DNR3D
|
|
Interface
|
|
| Interface Ethernet |
1 port Ethernet auto-adaptatif RJ45 10 M/100 M
|
| Événement |
|
| Événement De Base |
Détection de mouvement, alarme de falsification vidéo, exception
|
| Général |
|
| Fonction Générale |
Battement de coeur, anti-scintillement, miroir, protection par mot de passe, réinitialisation du mot de passe par e-mail |
| Conditions De Stockage |
-30 °C à 60 °C (-22 °F à 140 °F). Humidité 95 % ou moins (sans condensation)
|
| Pouvoir |
12 VCC ± 25 %, 0,4 A, max. 5 W, prise d'alimentation coaxiale Ø5,5 mm,PoE : 802.3af, classe 3, 36 V à 57 V, 0,2 A à 0,15 A, max. 6,5 W |
| Dimensions |
Ø76,6 mm × 164,4 mm (Ø3 × 6,5\")"
|
| Poids |
Environ. 425 g (0,9 livre)
|
| Protection |
IP67 : CEI 60529-2013
|
