CARACTERISTIQUES MATERIELLES | |
Standards et Protocoles | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p |
Interface | 24 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) 4 1000 Mbps SFP Slots 1 Console Port 1 Micro-USB Console Port |
Interface réseau | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) 1000BASE-X: MMF, SMF |
Nombre de ventilateurs | 2 |
Alimentation | 100~240VAC, 50/60Hz |
Ports PoE+ (RJ45) | Standard: 802.3at/af compliant PoE+ Ports: 24 Ports Power Supply: 384W |
Montage | Rack Mountable |
Consommation maximale | 29.02W (220V/50Hz with no PD connected) 468.7W (110V/60Hz with 384W PD connected) |
Max dissipation thermique | I99.02 BTU/h (with no PD connected) 1599.20 BTU/h (with 384W PD connected) |
PERFORMANCES | |
Taux de transfert de paquets | 41.7Mpps |
Bande passante/ backplane | 56Gbps |
Tableau d'adresses MAC | 16K |
Trame Géante | 9KB |
CARACTERISTIQUES LOGICIELLES | |
Qualité de Service QoS | Support 802.1p CoS/DSCP priority Support 4 priority queues Queue scheduling: SP, WRR, SP+WRR Port/Flow- based Rate Limiting Voice VLAN |
Fonctions N2 et N2+ | Static Routing DHCP Relay DHCP Server IGMP Snooping V1/V2/V3 802.3ad LACP (Up to 14 aggregation groups, containing 8 ports per group) STP/RSTP/MSTP BPDU Filtering/Guard TC/Root Protect Loopback detection 802.3x Flow Control L2PT |
Liste de contrôle d'accès | L2~L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p,DSCP, protocol and VLAN ID Time Range Based |
Sécurité | IP-MAC-Port Binding AAA 802.1x and Radius Authentication DoS Defend Dynamic ARP Inspection (DAI) SSH v1/v2 SSL v3/TLSv1 Port Security Broadcast/Multicast/Unknown-unicast Storm Control |
IPv6 | Dual IPv4/IPv6 stack Multicast Listener Discovery (MLD) Snooping IPv6 neighbor discovery (ND) Path maximum transmission unit (MTU) discovery Internet Control Message Protocol (ICMP) version 6 TCPv6/UDPv6 IPv6 ACL DHCPv6 Snooping IPv6 Interface |
AUTRES | |
Certification | CE, FCC, RoHS |
Contenu de l'emballage | Static Routing DHCP Relay DHCP Server IGMP Snooping V1/V2/V3 802.3ad LACP (Up to 14 aggregation groups, containing 8 ports per group) STP/RSTP/MSTP BPDU Filtering/Guard TC/Root Protect Loopback detection 802.3x Flow Control L2PT |
Système requis | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux. |
Environnement | Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
