| Caméra |
|
| Capteur D'image |
Capteur d'image CMOS 2 MP |
|
Max. Résolution
|
1920 (H) × 1080 (V) |
| Min. Éclairage |
0,02 Lux@(F2.0, AGC ON), 0 Lux avec IR |
| Temps D'obturation |
PAL : 1/25 s à 1/50 000 s ; NTSC : 1/30 s à 1/50 000 s |
| Jour Nuit |
Filtre anti-IR |
| Réglage De L'angle |
Panoramique : 0° à 360°, Inclinaison : 0° à 180°, Rotation : 0° à 360° |
| Lentille |
|
| Type D'objectif |
Objectif focal fixe, 2,8 mm et 3,6 mm en option |
| Distance Focale Et Champ De Vision |
2,8 mm, champ de vision horizontal : 96,5°, champ de vision vertical : 48,9° champ de vision diagonal : 120,5° 3,6 mm, champ de vision horizontal : 76,9°, champ de vision vertical : 40,6° champ de vision diagonal : 92,0° |
| Monture De Lentilles |
M12
|
| Illuminateur |
|
| Type De Lumière Supplémentaire |
IR
|
| Gamme De Lumière Supplémentaire |
Jusqu'à 20 m
|
| Image |
|
| Fréquence D'images |
PAL : 1080p à 25 ips NTSC : 1080p à 30 ips
|
| Mode Jour/Nuit |
Auto/Couleur/NB (noir et blanc)
|
| Réduction De Bruit |
DNR 2D
|
| Interface |
|
| Sortie Vidéo |
TVI/AHD/CVI/CVBS commutables
|
| Général |
|
| Matériel |
Métal
|
| Dimensions |
165 mm × 62 mm × 58 mm (6,50" × 2,44" × 2,28")
|
| Poids |
400 g (0,88 livre)
|
| Approbation |
|
| Protection |
IP66
|
