Paramètres réseau | |
Interface | 24 × 10/100 Mbps PoE ports, 2 × Gigabit combos |
Type des ports | RJ45 port, full duplex, MDI/MDI-X adaptive |
Standards et Protocoles | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
Méthode de Transmission | Store-and-forward switching |
Capacité de commutation | 8.8 Gbps |
Taux De Transfert De Paquets | 6,547 Mpps |
Ports Hautement Prioritaires | Ports 1 à 8 |
Cache Interne | 2,75 Mbits |
Table D’adresses MAC | 4 K |
Général | |
Poids net | 3.3 kg |
Alimentation | 100 à 240 V CA, 50/60 Hz, Max. 6,5 A |
Puissance Maximale Du Port | 30W |
PoE Port | De 1 à 24 |
Consommation D’énergie Au Ralenti | 30W |
Max. Consommation D’énergie | 400W |
Dimension (L × H × L) | 440 mm × 44 mm × 220.8 mm (17.3” × 1.73” × 8.7”) |
