CARACTERISTIQUES MATERIELLES | |
Standards et Protocoles | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x |
Interface | 24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) 4 Gigabit SFP Slots |
Interface réseau | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) 1000BASE-X: MMF, SMF |
Nombre de ventilateurs | 2 |
Consommation | |
Ports PoE+ (RJ45) | Standard: 802.3at/af compliant PoE+ Ports: 24 Ports Power Supply: 192W |
Trame Géante | |
Consommation maximale | 30.77W (110V/60Hz with no PD connected) 235.8W (110V/60Hz with 192W PD connected) |
Max dissipation thermique | 104.99 BTU/h (with no PD connected) 804.55 BTU/h (with 192W PD connected) |
CARACTERISTIQUES LOGICIELLES | |
Qualité de Service QoS | Support 802.1p CoS/DSCP priority Support 8 priority queues Queue scheduling: SP, WRR, SP+WRR Port/Flow- based Rate Limiting IPv6 QoS* Voice VLAN |
Fonctions N2 et N2+ | Static Routing DHCP Relay DHCP Server IGMP Snooping V1/V2/V3 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group) Spanning Tree STP/RSTP/MSTP BPDU Filtering/Guard TC/Root Protect Loopback detection 802.3x Flow Control LLDP, LLDP-MED |
VLAN | Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs) MAC/Protocol-based VLAN |
Liste de contrôle d'accès | L2~L4 package filtering MAC ACL IP ACL Combined ACL IPv6 ACL |
IPv6 | Dual IPv4/IPv6 stack Multicast Listener Discovery (MLD) Snooping IPv6 neighbor discovery (ND) Path maximum transmission unit (MTU) discovery Internet Control Message Protocol (ICMP) version 6 TCPv6/UDPv6 |
Applications IPv6 | DHCPv6 Client Ping6 Tracert6 Telnet (v6) IPv6 SNMP IPv6 SSH IPv6 SSL Http/Https IPv6 TFTP |
AUTRES | |
Certification | CE, FCC, RoHS |
Contenu de l'emballage | T1600G-28PS Power Cord Installation Guide Resource CD Rackmount Kit Rubber Feet |
Environnement | Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90%RH non-condensing Storage Humidity: 5%~90%RH non-condensing |
Système requis | Microsoft® Windows® XP, Vista™ or Windows 7, Windows 8, MAC® OS, NetWare®, UNIX® or Linux. |
